Graphtec CE7000-60 (24") cutting plotter

SKU
5002
In stock
Processing
2 WEEKS
$3,096.33
Description
Graphtec makes everything EASY. The CE7000 Series comes complete with our full complement of Graphtec Software along wit More details

The CE7000 Series also boasts our popular cutting channel feature to allow easy PERFORATED CUT or THROUGH CUT operations.

The CE7000 Series comes complete with our full complement of Graphtec Software along with our NEWLY ADDED Ethernet Connectivity.

Software includes Cutting Master 4 plug-in for Adobe & Corel Users and our popular Graphtec Pro Studio software for design & cut graphics. The CE7000 series works with both PC and MAC platforms, or use the handy new USB Thumb Drive Port if needed.

The Graphtec CE7000 Series cutting plotter is the perfect solution for those
looking to increase production with greater efficiency for:
SIGNAGE GRAPHICS • PRINT & CUT GRAPHICS • POP & PACKAGING • AUTOMOTIVE MARKETS and many more….

Updated Features from the CE6000:

NEW DATALINK BARCODE SYSTEM

Save time and reduce the chance of production errors by using barcodes to automatically process multiple jobs at the touch of a button.

NEW THROUGH CUT CHANNEL PER MODEL

Separate tool positions for contour and die cutting ensures the longevity of your blades and cutting strip when creating decals and graphics that are effortlessly popped out of sheet and roll media. Easily allow perforated cut or through cut operations.

NEW USB THUMB DRIVE SUPPORT FOR OFFLINE CUTTING

A new secondary USB port has been added for placing thumb drives so jobs can be uploaded and cut without the need of a computer. Select barcode function or select file directly from the thumb drive.

Possible Applications:

  • Stickers/decals
  • Window signage
  • Heat transfer apparel
  • Window tint film
  • Paint protection film

NOTE: PLEASE CONTACT US FOR SHIPPING QUOTE TO YOUR LOCATION. PRODUCT IS BULKY.

NEW 8.0 ARMS for Fast and Accurate PRINT & CUT Applications
DATALINK Bar Code Feature for Maximum Productivity
NEW USB Thumb Drive Connectivity - NO Computer Needed!
No
Quiet precision servo motor
New Increased Max Cutting Speed: CE7000-40 | 24" per second at all direction; CE7000-60 | 35" per second 45deg; CE7000-130 | 39" per second at 45deg
Cutting Force: 450 gf
5mm precision for small lettering
New 25% faster ARMS 8.0 Optical Eye For Continuous Cut Capabilities (Barcode Reader) with XY compensation feature
Reliable Long-Length Tracking (Over 15ft!)
Graphic LCD Display With Back Light
A network connection is now possible through a network interface enabling the use of TCP/IP protocols to transfer cut data.
New built-in convenient tool storage.

TECHNICAL SPECIFICATIONS
Motor Type: Servo
OS Compatibility: Windows, MAC
Contour Cutting: Yes - Automatic
Power cord: The type of cord is different by destination
USB Cable: 9.5 feet long
Cutting blade holder: PHP33-CB09N-HS
Cutting Blade: CB09UB
Loupe: PM-CT-001
Fiber-tip pen holder: PHP31-FIBER
Water-based fiber-tip pen: KF700-BK (black)
Stand: Parts kit
Roll Media Tray: Only for CE7000-40
Stand for CE7000: Standard accessory for 60/130
Printed Documents: Setup Manual, Cutting Blade Manual, and Safety Manual

Software (all models):
Graphtec Pro Studio - 1 License: Extremely Powerful Design Software (For Windows)
Graphtec Studio (For MAC)
Cutting Master 4 (For Adobe Illustrator & CorelDRAW Integration)
Windows Driver
